Monel Flat Bars: High-Quality, Corrosion-Resistant Solutions from Velocity Steel India

Introduction to Monel Flat Bars

Velocity Steel India is a leading supplier and stockist of Monel Flat Bars, which are suitable for corrosion-resistant applications. Our high-quality bars provide exceptional strength, durability, workability, and a flawless finish. We provide long-lasting Monel 400 flat bars in a variety of sizes and forms, made from high-quality materials for excellent performance and low maintenance.

Monel K500 Flat Bars are rectangular metal bars known for their excellent strength and corrosion resistance. Available in both hot-rolled and cold-rolled forms, they are durable and ideal for heavy-duty applications.

The Monel 400 Flat Bar is made from nickel-based Monel Alloy 400, which contains manganese and copper. It is rectangular and comes in a variety of sizes. These flat bars are used in various industries such as marine engineering, chemical processing, oil and gas.

Inconel Flat Bar

Specifications

Specification Description
Grade Monel 400 / Monel K-500
Dimensions EN, DIN, JIS, ASTM, BS, ASME, AISI
Specifications ASTM B 164 / SB 164 / SB 865
Standards EN, DIN, JIS, ASTM, BS, ASME, AISI
Finish Bright, Polish & Black
Form Round, Square, Hex (A/F), Rectangle, Wire, Wire-mesh, Forging Etc.
Length 2 metres – 6 metres (8 feet to 20 feet)
Thickness 1 mm to 100 mm

Types of Monel Flat Bars

  • Monel 400 Flat Bar
  • Monel K500 Flat Bars
  • Monel Alloy K500 Flat Bar
  • Hot-Rolled Monel Flat Bars
  • Cold-Rolled Monel Flat Bars
  • Solid Monel Flat Bars
  • Cladded Monel Flat Bars
  • ASTM Monel Flat Bars
  • DIN/EN Monel Flat Bars
  • Monel Alloy 400/K500 Square Bar
  • Monel Alloy 400/K500 Hex Bar
  • Monel Alloy 400/K500 Rectangular Bar
  • Monel Alloy 400/K500 Flat Bar
  • Monel Alloy 400/K500 Bright Bar
  • Monel Alloy 400/K500 Forged Bar

Chemical Properties

Grade C Mn Si S Cu Ni Fe
Monel 400 0.30 max 2.00 max 0.50 max 0.024 max 28.0 - 34.0 63.0 min 2.50 max
Monel K500 0.25 max 1.5 max 0.50 max 0.010 max 27.0 – 33.0 63.0 min 05 – 2

Mechanical Properties

Grade Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Monel 400 8.8 g/cm3 1350 °C (2460 °F) Psi – 80,000, MPa – 550 Psi – 35,000, MPa – 240 40%
Monel K500 8.44 g/cm3 1350 °C (2460 °F) Psi – 1,60,000, MPa – 1100 Psi – 1,15,000, MPa – 790 20%
